QuickSpecs
Compaq AlphaStation XP1000
DA-10030 Canada — Version 17 — July 31, 2001 6
Options
Step 6 −−−− External Storage −−−− Optional
• UltraSCSI configurations require UltraSCSI components (controllers, shelves, disks, cables)
Step 6a -- StorageWorks BA356/BA370 Options
Storage Controllers/Adapters for StorageWorks BA356/BA370 Pedestals and Shelves
• Storage controllers require a minimum operating system revision of Tru64 UNIX V4.0F or OpenVMS V7.1-2 unless noted otherwise.
• Each storage controller/adapter uses one PCI slot
Maximum # Supported
Tru64 UNIX OpenVMS
PCI 1-port UltraSCSI single-ended adapter; includes internal 68-pin and 50-pin HD
connectors and external 68-pin HD connector; requires BN38C-xx cable (2-20m) to
connect to single ended UltraSCSI shelf
2 2 SN-KZPBA-CA
PCI 1-port UltraSCSI differential adapter; includes external 68-pin HD connector;
requires BN38C-xx cable (2-25m) to connect adapter to Differential UltraSCSI
shelf or RAID controller
2 - SN-KZPBA-CB
68-pin HD male-to-VHDCI male UltraSCSI cable; required for each external UltraSCSI
shelf attached to KZPBA-CA/CB adapter
BN38C-xx
PCI 1-port UltraSCSI RAID controller with 4-MB cache memory, includes RAID Array
230/Plus subsystem software and documentation kit and VHDCI female connector;
tape drives not supported − 18.2-GB or higher disk drives not supported on
KZPAC-xx RAID controllers
1 1 SN-KZPAC-AA
PCI 3-port UltraSCSI RAID controller with 4-MB cache memory, includes RAID Array
230/Plus subsystem software and documentation kit; tape drives not supported;
SCSI cable required for each active port; requires BN31K-0E for external third-port
connection − 18.2-GB or higher disk drives not supported on KZPAC-xx RAID
controllers
1 1 SN-KZPAC-CA
PCI 3-port UltraSCSI RAID controller with 8-MB cache memory, includes RAID Array
230/Plus subsystem software and documentation kit; tape drives not supported;
SCSI cable required for each active port; requires BN31K-0E for external third-port
connection − 18.2-GB or higher disk drives not supported on KZPAC-xx RAID
controllers
1 1 SN-KZPAC-CB
Cache battery backup for KZPAC controller KZPSC-UB
VHDCI male-to-VHDCI male UltraSCSI cable,
xx=02, 2E(2.5), 03, 05, 10, 20 m)
Note: Manufacturing may substitute BN37A-02 cable for specific cabinet
configurations
BN37A-xx
SCSI cable/bulkhead assembly kit with KZPAC-CA/CB, allows external connection of
one third port
BN31K-0E
SCSI cable/bulkhead assembly kit with two ports for KZPAC-CA/CB, allows external
connection of two third ports
KZPAC-SB
PCI 3-channel 64-bit Ultra2 LVD RAID controller, 64-MB cache – supported with DS-
BA356-SG and DS-BA35X-FC only
1 - DS-KZPCC-CE
