22 • 463360408
CAUTION
• Failure to install tank correctly may allow gas hose to
be damaged in operation, resulting in the risk of fire.
See Use and Care section to correctly Leak Test and
perform the Burner Flame Check.
Failure to install grease cup clip and cup
will cause hot grease to drip from bottom
of grill with risk of fire or property damage.
CAUTION
Grease Cup Clip
Grease Cup
12
13
LP Tank
Tank Thumbscrew
•
Hang grease cup clip from bottom of firebox and place grease cup into grease clip.
•
(over-fill protection device)
to grill and regulator.
•
Place LP tank into hole in bottom shelf with tank collar opening facing to side as shown. Finger tighten tank thumbscrew to hold LP
tank securely in place.
LP tank is sold separately. Use only with an OPD equipped LP tank. Fill and leak check before attaching
