Char-Broil 463440109 User Manual
Page 15
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the methood of assembly remains the same.
PARTS LIST
15
Key Qty Description
JJ
1 GREASE CUP
KK
1 CLIP, F/ GREASE CUP
LL
1 TANK EXCLUSION
MM
2 LEG EXTENDER
NN
1 WING SCREW F/ TANK
OO
2 LID BUMPER, ROUND
PP
1 WIRE, F/ SIDEBURNER
1 HEAT SHIELD F/ EI MODULE
NOT Pictured
…
1 VENTURI CLIP F/ SB
…
1 HARDWARE PACK
…
1 ASSEMBLY MANUAL, ENGLISH
…
1 ASSEMBLY MANUAL, SPANISH
Key Qty Description
A
1 FIREBOX
B
4 TUBE BURNER
C
1 ELECTRODE, MAIN BURNER
D
3 CARRY OVER TUBE
E
1 CONTROL PANEL, MAIN
F
1 ELECTRONIC MODULE, W/BUTTON
G
1 BUTTON, F/ ELECTRONIC MODULE
H
1 VALVE/ HOSE/ REGULATOR
I
5 BEZEL F/ KNOB
J
5 CONTROL KNOB
K
1 GRILL LID
L
1 LOGO PLATE
M
1 TEMPERATURE GAUGE
N
2 LID BUMPER, RECTANGLE
O
1 GRILL LID HANDLE
P
1 TOP LID HARDWARE
Q
4 HEAT TENT
R
3 COOKING GRATE
S
1 SWING AWAY GRID
T
1 LEFT SIDE SHELF
U
1 DRIP PAN F/ SIDEBURNER
V
1 SIDEBURNER LID
W
1 CONTROL PANEL F/ LEFT SHELF
X
1 SIDEBURNER GRATE
Y
1 SIDEBURNER
Z
1 ELECTRODE, F/ SB
AA
1 RIGHT SIDE SHELF
BB
1 CONTROL PANEL F/ RIGHT SIDE SHELF
CC
1 CART, RIGHT SIDE
DD
1 MATCH HOLDER
EE
1 CART, LEFT SIDE
FF
1 FRONT PANEL
GG
1 BOTTOM SHELF
HH
1 AXLE ROD
II
2 WHEEL
