uSign User Manual
6.3 Physical housing uSign 200
Overall size 129mm wide (5.1 in)
146mm length (5.75 in)
40mm thick including back plate (1.57 in)
Display 3.3-inch diagonal signature area
6.4 LCD screen & Resistive touch pad
Touchpad Resistive, transparent, pressure-sensitive screen
Display STN monochrome LCD
Sampling Rate Up to 190 samples per second
Touchpad Resolution up to 929 dpi
Display Resolution LCD Resolution: 192 x 64 dots
Overlay Screen Removable/Field replaceable signature surface
6.5 Communication interface
RS232
Baud rates
1200 to 115200
Default 9600 baud, data bits – 8, Parity – none, Stop bit – 1
USB 2.0 Full Speed (Common Device Class)
6.6 LED
Two individual LEDs (one green & one red)
Signature Pad or Host controlled
6.7 Agency Approvals
FCC Class B, & CE,
The uSign 100 is UL Listed
The product is RoHS compliant.
6.8 Electronics MTBF
Electronics MTBF 200,000 POH, based on Bellcore standard.
6.9 Electro-Static Discharges (ESD)
The electronics must survive ESD of 4kV contact, and 8kV air discharge. Meets or
exceeds IEC 1000-4-2.
6.10 Environmental
Temperature ranges
Operating 1 to 45 C (34 to 113 F)
Storage (sealed container) -10 to 70 C (14 to 158 F)
Relative humidity
