TFX-FS360 User Manual
7 2010-07-20/14:53
O
PERATING
I
NSTRUCTIONS
Operating Modes
The TFX-FS360 can be operated in the following ways;

As a manual followspot using on-board manual controls or slaved to a DMX-512 controller for cue
changes.

As a static spot controlled by a DMX-512 controller.
Followspot Mode
Enter Manual Mode by pressing the FUNCTION SELECT button until the MANUAL LED is turned
on.
B UTTONS F UNCTION
DIMMER Min. and Max. buttons adjust the intensity of the light output respectively.
SHUTTER
The electronic shutter provides instant lights on or shuts all light output off for a
blackout state.
Color Buttons
The following colors can be immediately selected by pressing each individual
button:
UV, Magenta, Orange, Yellow, Green, Blue, red and White
FUNCTION Press FUNCTION button to switch between manual and DMX control modes.
UP/DOWN
The Up/Down buttons are available when in DMX mode. Press the UP and
DOWN buttons to locate the DMX channel value desired.
