TFX-FS360 User Manual
4 2010-07-20/14:53
I
NTRODUCTION
Features

2-channel DMX-512 followspot
 7 dichroic colors + white: (red, blue, green, yellow, orange, magenta, UV purple)
 Variable electronic dimmer (0-100%)

Variable mechanical iris

Variable mechanical focus
Additional Features
 Followspot stand (CH-W28)
Options

Single gobo slot with 4 free gobos
DMX Channel Summary
C HANNEL F UNCTION
1 Color
2 Dimmer
Product Overview
Gobo-holder
Located and inserted on
the bottom side of the
followspot.
Iris
Control panel
Lamp access
Focus
Focus handles
Yoke
Control panel
Gobos included
DMX
Input/Output
Optional
CH-W28 Tripod
w/casters
