Fuses Usage
INTERIOR
LAMP
Hush Panel Lamps, Puddle Lamps,
Overhead Courtesy Lamp Assembly
RT
FRT DR MOD
Passenger’s Door Module
RIM
Rear Integration Module (RIM),
Ignition Switch, Key Lock Cylinder
REAR FOG
LAMP
Rear Fog Lamps (Export Only)
SUSPNTN Suspension Module
VICS/RAP
TV Tuner Assembly, Vehicle
Information Communication
System (VICS) Module, Sunroof
SPARE Not Used
POWER
SOUNDER
Power Sounder, Inclination Sensor
AFTERBOIL Afterboil Heater Pump
CANISTER
VENT
Canister Vent Solenoid
FUEL
PUMP MTR
Fuel Pump Motor
REAR HVAC Rear Climate Control System
Fuses Usage
R FRT HTD
SEAT MOD Passenger’s Side Heated
Seat Module
REAR HATCH Rear Hatch Latch
AIR BAG Sensing Diagnostic Module (SDM)
REAR DEFOG Rear Window Defogger Element
IGN 1
Shifter, Power Sounder, Rear
Parking Aid, Rearview Mirror, RIM
SPARE Not Used
SPARE Not Used
J Cases Usage
SUNROOF MOD Power Sunroof Module
POWER
LIFTGATE
Power Liftgate
Circuit
Breakers Usage
DR MOD
PWR C/B
Door Modules
