Xpres SubliJet IQ Epson WP-4015 (Mac ICC Profile Setup): Print & Setup Guide Photoshop CS6 - Manual (Page 3)

PAGE 3 of 8 >>
SubliJet-IQ: Epson WorkForce Pro WP-4015 DN - MacProfile
Setup and Print Guide - Photoshop CS6
FIGURE 3
2
1
K. If Conversion Options are not visible, click More Options (see FIGURE 2)
L. Engine: Adobe (ACE) (see FIGURE 2)
M. Intent: Perceptual (see FIGURE 2)
O. Once your settings match, click Save (see FIGURE 2). This will open the Save window (see
FIGURE 3). NAME your new preset in the File Name field and click Save when complete.
P. Click OK to complete setup (see FIGURE 2)
N. Check Use Black Point Compensation (see FIGURE 2)
3. In the menu bar, click File > New… (Command+N). In the New Document window, match your settings
to those shown below (see FIGURE 4).
A. Color Mode: RGB Color
FIGURE 4
C. Color Profile: Adobe RGB (1998)
D. Click OK to save your changes and continue
A
C
D
B
B. Click the down arrows next to Advanced to view Color Profile:
