Xpres SubliJet E Epson SureColor T3000 (Power Driver Setup): Print & Setup Guide Illustrator CS - CS5 - Manual (Page 5)

SubliJet-E: Epson SC T3000
PowerDriver Print Setup Guide: Illustrator CS-CS5
PAGE 5 of 6 >>
Printing from Illustrator with PowerDriver E SC-T3000
7) With the correct Color settings entered, you are now ready to print. In the Menu Bar, click File > Print. In
the Print window, match your settings to those shown below (see FIGURE 8).
B
C
FIGURE 8
B. Size: Defined by Driver
C. Click Color Management to view the color management settings.
A. Printer: PowerDriver E SC-T3000
PowerDriver E SC-T3000
6) Everytime an image is opened or imported in Illustrator, ensure that RGB color mode has been selected.
In the menu bar, click File > Document Color Mode > RGB Color. A check mark should now be visible
beside RGB Color (see FIGURE 7).
FIGURE 7
C
A
B
A
