Xpres SubliJet IQ EPSON Stylus PRO 4880 (Windows Power Driver Setup): Print & Setup Guide Photoshop CS5 - Manual (Page 2)

2. The Color Settings window should now be open (see FIGURE 2). Match your settings to the ones
shown below:
PAGE 2 of 5 >>
SubliJet IQ: Epson Stylus Pro 4880
Setup and Print Guide: Photoshop CS5 (cont’d 2:5)
RGB: Adobe RGB (1998)
CMYK: U.S. Web Coated (SWOP) v2
Gray: Dot Gain 20%
Spot: Dot Gain 20%
RGB: Convert to Working RGB
CMYK: Preserve Embedded Profiles
Gray: Preserve Embedded Profiles
Profile Mismatches: Check Ask When Opening
and also check Ask When Pasting
A.
B.
C.
D.
E.
F.
G.
H. Missing Profiles: Check Ask When Opening
If Conversion Options is not visible, click More
Options
Engine:
Adobe (ACE)
Intent: Perceptual
Once your settings match, click Save. This
will open the Save window (see FIGURE 3).
I.
J.
K.
L.
M.
FIGURE 2
H
A
B
C
D
E
F
G
K
L
I
J
M
