Workrite Ergonomics | 800.959.9675 www.workriteergo.com
#1500 150 - Rev B
Attach Astra
Attach assembled lamp to Mount
E
Mount
Qty: 1
Parts
Assembly Instructions for
Astra
TM
Panel System Mount
Attach Mount to Panel Mounting Bracket
Determine if mounting on left or right of vertical
panel seam.
Attach Mount to Panel Mounting Bracket with
four screws provided, using a Phillips-head
screwdriver.
1
a
Verify that you have all the hardware needed for the assembly.
A
Panel Mounting
Bracket
Qty: 1
B
Panel Mounting
Hook
Qty: 1 each
E
A
Phillips-head screwdriver
C
10-32 x .75"
Phillips-head screw
Qty: 2
Astra Light
Workrite Astra
Wor krit e A str a
2
Attach Panel Mounting Hook to Mount
Slide teeth of appropriate Mounting Hook
(left or right) all the way through holes in
Mounting Bracket.
Tip Mounting Hook and insert teeth into
panel system slots, push down for secure
connection.
Insert and tighten Phillips-head screws to
eliminate movement.
a
a
B
b
b
c
c
F
3
a
a
Right-side mounting Left-side mounting
Right-side mounting Left-side mounting
F
M5 x 10mm
Phillips-head
Screws
Qty: 4
C or D
D
10-32 x .5"
Phillips-head screw
Qty: 2
C or D
Mount must have secure fit.
Use longer #10 screws if they
will fit without sticking out.
Otherwise, use shorter screws.
