Publication Part No. V4015-4980 Issue 2 33
Troubleshooting
Problem Check
No coordinate information appears in the
message window (13) when the HPM is
turned on.
Close the Quattro application and restart
the application.
No coordinate information appears in the
message window (13) after zeroing the
lens and the head
The PDA is unable to establish
communications with the Quattro-SE
pedestal—verify coms indicator (7) is
unticked.
Check power and ethernet cable
connections at either end of the pedestal
cable management system (into the
pedestal base and the HPM).
If unsuccessful, restart the PDA and power
cycle the HPM.
Coordinate information does not update
and no tracking data is received.
On the PDA, check that the pedestal ‘NAV
MODE’ is turned on—verify navigational
mode indicator (6) is ticked. See
Communicating navigational and
positional data to the VR system on
page 26.
On the PDA, check that both genlock
indicators (8) are ticked. The left hand box
indicates a genlock signal is present at the
pedestal base and the right hand box
indicates a genlock signal is present at the
head. If either box is unticked, check the
genlock cable connections at the HPM and
the pedestal.
