20
Installation
CAUTION
SHARP EDGES
RISK OF SERIOUS INJURY
Sharp edges are present inside the Wine Guardian system.
Pre-installation Test
Test the system before installing it to check for non-visible shipping damage.
To test the system:
 Set the system on the floor or a sturdy level surface
 Plug in the system
 Press the on/off switch, control illuminates. This indicates the system has power.
 The built in timer prevents short cycling and keeps the system from
turning on right away. The system comes on and runs as long as the
temperature of the space is above the thermostat set point. After several
minutes, cold air comes out of the system from the evaporator section side and
hot air comes from the condenser section. Listen for any unusual noise or
vibration.
Air Flow Illustration
COLD WINE CELLAR
AIR OUT
WARM WINE
CELLAR AIR IN
WARM AMBIENT
AIR OUT
COLD AMBIENT
AIR IN
