Vetter Ultra Flat Bags S.Tec 10 bar
Page 13/15
7.
Technical data
Ultra Flat Bags S.Tec 10 bar
Unit
UF 1 S.Tec UF 4 S.Tec UF 7 S.Tec UF 12 S.Tec
Art. No.
1315006000 1315006100 1315006200 1315005900
Lift power
to
1.1
3.8
7.0
11.6
US tons
1.2
4.2
7.7
12.8
Lift height
cm
7.5
12.0
16.5
20.3
inch
3.0
4.7
6.5
8.0
Insertion height*
cm
1.6
1.6
1.6
1.6
inch
0.6
0.6
0.6
0.6
Dimensions
cm
14 x 13
25.5 x 20
29.5 x 29.5 37 x 37
inch
5.5 x 5.1
10 x 7.9
11.6 x 11.6 14.6 x 14.6
Operating max.
pressure
bar
10
10
10
10
psi
145
145
145
145
Test pressure
bar
16
16
16
16
psi
232
232
232
232
Air requirement
at 10 bar/145 psi
l
3.85
24.75
48.4
92.95
cu.ft.
0.1
0.9
1.7
3.3
Nominal capacity
l
0.35
2.25
4.40
8.45
cu.ft.
0.01
0.08
0.16
0.30
Burst pressure,
min.
bar
40
40
40
40
psi
580
580
580
580
Weight ca.
kg
0.4
1.0
1.7
2.4
lbs
0.88
2.20
3.75
5.29
* around valve + 6 mm (0.2 inch)
All rights reserved for technical changes within the scope of product improvement.
