Chapter 2: specifications – Torbal FA Series User Manual
Page 5

- 5 -
Instruction Manual
– FA Series Force Gauge
Model
FA50
FA200
FA500
Maximum Capacity
50N (~5kg)
200N(~20kg)
500N(~50kg)
Readability (d)
0.01N (1g)
0.05N (5g)
0.1N (10g)
Accuracy
±0.2%
Measurement Units
N, kgf, lbf, ozf, kg, lb, oz
20%
Operating Temperature
-10 to 40°C
Internal Resolution
24 bits
Process Speed
10 or 40 measurements per second
Internal Memory
Capacity
8 files x 800 measurements each
Interface
USB
Assisting Software
FM (time characteristic, statistical analysis, data archiving)
Display
LCD Graphical 61x34mm
Measurement Options
Peak value measurement, continuous measurement, dynamic measurement (force vs
time plot)
Power Supply
Lithium polymer batteries set 1000mAh (LP703048P6H type)
+ supply ~115V 60Hz / 12VDC @ 1.2A
Battery Life
~20h (~45h backlighting off)
Measuring Rod
11mm (thread M6x9mm)
Dimensions
210x110x40mm (8.4x4.4x1.6in)
Weight
700g (1.5lb)
Chapter 2: Specifications
