Instruction Manual – FA Series Force Gauge
10.2 Threshold
The THRESHOLD option is used to set up parameters when using Min/Max measurements. When the
Min/Max values are exceeded, the device’s buzzer sounds. To get to this screen go to APPLICATIONS in the
Main Menu.
1. To enable the Min/Max notification, change the status from OFF to ON.
2. Set the Min and Max parameters.
3. Set the buzzer type.
There are 2 options that can be used to signal that the the
parameters have been exceeded:
- MODE1 – short signal upon exceeding MIN, long signal
upon exceeding MAX,
- MODE2 – interrupted signal below MIN, continuous
signal above MAX, no signal for OK.
THRESHOLD
1. Status:
2. MIN 1.000kg
3. MAX 2.000kg
4. Buzzer
5. Exit
