Vega Specifications
15
Vega Specifications
Power
AC/DC Power Required
Reader : 10-16 VDC, 8 W maximum at 12 V when transmitting
Optional AC Power Adapter: 100-240 VDC, 50-60 Hz, 10 W maximum when
transmitting
Note
If an AC Power Adapter supply is used it must meet the following criteria:
- Be UL Listed
- Meet the above operating specs
- The output must comply with SELV and LPS characteristics
- Have a maximum operating ambient temperature that meets or exceeds the intended
Vega operating temperatures as covered under the UL Listing of the power supply.
Environment
Operating Temp
Reader: -40 C to +75 C
Note
If an external DC power supply with a lower operating ambient temperature, as covered
under the UL Listing of the power supply, is used then the operating ambient temperature of
the Vega would be reduced accordingly.
Storage Temp
Reader: –40C to +85C
