Symtech HBA 5 User Manual
Page 4
4
1.0
GENERAL
ASSEMBLY
&
CALIBRATION
1.0
GENERAL
ASSEMBLY
&
CALIBRATION
6
7
5
8
9
1
2
4
3
Front
Parts List
Accessory Box
(1) AC Battery Charger
(1) Front Eccentric Axle assembly w/ wheel and handle
(1) Rear Eccentric axle assembly w/ wheel and handle
(1) Wheel w/ straight axle bolt assembly
(1) Mirror assembly
(2) 1/4-20 x 1 1/2 Allen head cap screws
(2) 1/4 steel washers
(1) Laser assembly
(1) Glide Plate Assembly
Tension
Adjustment Screws
