Page 32
32 •
4. OVERVIEW
4.1
Controls/Features
4.2
Information on device and on rating plate
2
1
3
seca 760/761/762
:
2
1
3
seca 750
:
No. Control/Feature
Function
1
Adjusting wheel
For adjusting the display.
2
Scale ring
• Protects the pointer and dial
• Can be removed for cleaning (not
seca 750
)
3
Transport lock
• Prevents any relative movement between the weighing
platform and lower section of the housing during
transport
• Can be used as a wall spacer.
Text/Symbol
Meaning
Model
Model number
Ser. no.
Serial number
Follow instructions for use
Conformity symbol in compliance with directive 2009/23/
EC for non-automatic scales (calibrated models)
e
Value in units of measurement used to classify and
calibrate a scale (calibrated models)
d
Value in units of measurement which gives the difference
between two consecutive display values
