QOMO Hite Vision Interactive Whiteboard User Manual
© Copyright 2012 QOMO HiteVision, LLC. All Rights Reserved
7
2. Drill 8 holes for expansion bolts on the wall according to your preference
(Figure A). Install the wall-mount brackets and tighten the bolts into each
hole. Hang up the whiteboard with the calibration hole D in four corners
in the wall-mounting bolts (Figure B).
A B A
C
A
B A
Figure A
