B R W - 5 0 0 B L A S T M A X I N S T A L L A T I O N M A N U A L TM
PARTS LIST
Spacer Gasket
Setting Block
For BRW-509
Setting Block
Mullion
Extrusions
DESCRIPTION ITEM
BRW-500
BRW-501
Mullion
BRW-502
Mullion Face Cap
BRW-503
SSG Mullion
GP-131
GP-132
Gaskets
Side Block
SHP-17
BRW-504
SSG Mullion
BRW-505
Jamb Mullion
BRW-506
Head / Sill
BRW-507
Head, Jamb &
Sill Face Cap
Head & Sill
Filler
BRW-508
BRW-509
Horizontal
Screw Spline
DESCRIPTION ITEM
BRW-510
Horizontal
Face Cap
BRW-511
2 7/8" Deep
False Horizontal
BRW-512
9/16" Deep False
Horizontal
Extrusions
DESCRIPTION ITEM
BRW-513
Jamb Mull
w/ Anchor Pocket
BRW-514
Jamb Mull
Snap Filler
SHP-92
Setting Chair
for BRW-506
BRW-102
Setting Chair
for BRW-509
BRW-103
Exterior Gasket
FL-66
