Glazing-detail-ssg, Frame installation – Oldcastle BuildingEnvelope BRW-500 BlastMax User Manual
Page 20
Phone: 1-866-OLDCASTLE (653-2278)
Web Address: www.oldcastlebe.com
B R W - 5 0 0 B L A S T M A X I N S T A L L A T I O N M A N U A L
TM
FRAME INSTALLATION
APPLY SEALANT CONTINUOUS
ALONG SNAP LEG BEFORE ASSEMBLY
INSTALL BACKER ROD AND
RUN CONTINOUS SEAL
SEAL BETWEEN FACE CAPS.
MARRY SEAL WITH VERTICAL
SEAL AT GLASS FACE, MULL CAP
SEAL AND PERIMETER SEAL
FIGURE 18
