6' competitorrr gearbox parts breakdown parts list – Modern AG Competitor User Manual
Page 65
Competitorrr Cutter - 65
item
Part no.
Quantity
description
401-0007
1
Gearbox Complete
1
501-0023
1
Housing
2
501-0024
1
Spacer
3
501-0021
3
Snap ring
4
501-0022
1
output Shaft, 12 Spline
5
501-0011
1
Bearing
6
501-0012
1
input Shaft
7
501-0757
1
plug, pressure relief
8
501-0014
1
input Gear 22t
9
501-0016
Var
Gasket
10
501-0015
1
Snap ring
11
501-0020
1
Seal
12
501-0019
1
input Cap
13
501-0018
10
Cap Screw
14
501-0017
10
Lockwasher
15
501-0025
3
Bearing
16
501-0026
Var
Gasket
17
501-0028
1
output Cap
18
322-1267
1
Seal
19
401-7559
1
Hub (for reference only)
20
401-7471
1
Flatwasher
21
401-7263
1
Hex nut 1" Castl.
22
900-8951
1
Cotter pin
23
501-0254
1
plug
26
412-7978
1
retaining ring
6' CoMPetitorrr GearBoX Parts BreaKdown
Parts List
