Competitorrr Cutter - 55
Item Part No. Quantity Description
1 101-0005 1 Welded Deck, 5’
2 401-0007-01 1 Gear Box
3 343-135 1 PTO Complete, 5’
5 115-7135 1 A-Frame Spacer
6 900-0003 1 Safety Cone
7 116-1025 2 Stiff-Arm, 4’ & 5’
8 116-1030 1 Tailwheel Boom, 5’
9 412-0081 1 Cotter Pin, 3/8 x 3 ½
10 101-7552 2 Tailwheel Spacer
11 116-6487-01 1 Tailwheel Yoke
12 103-209 1 Tailwheel, 4 x 8
13 900-1836 1 Hub, 5/8 Fabricated
14 412-9099 1 Owner Manual Holder
15 412-5283 1 Bolt, 5/8 x 7 ½ Gr. 5
16 115-7134 1 Pivot Hitch
17 150-10 2 Cat 1 Lift Pin w/nut & lockwasher
18 412-5284 1 Nylock Nut 5/8
19 412-0023 6 Bolt, 5/8 x 2 Gr. 2
20 412-0059 9 Hex Nut 5/8
21 412-11319 3 Bolt, 5/8 x 4 Gr. 2
22 412-0073 9 Lockwasher, 5/8
23 412-0023-02 4 Bolt, 5/8 x 2 GR5
24 412-5284 4 Nylock Nut, 5/8
25 412-2130 1 Bolt, ¾ x 6 Gr. 2
26 412-0060 1 Nylock Nut, ¾
27 412-2003 4 Bolt, 5/16 x ½ Gr. 5
28 412-6769 1 Carriage Bolt ½ x1½ Gr.5
29 412-0058 1 Hex Nut, ½
30 412-0072 1 Lockwasher, ½
31 116-1655 1 Inspection Cover Plate
32 412-0075 4 Flat Washer 3/8
33 412-31823 2 Self Tap Screw 1/4 x 1
34 412-2088 1 Bolt, 1/2 x 3 1/4 GR2
35 412-3243 1 Nylock Nut, 1/2
36 104-1907 1 Rear Rubber Safety Guard
37 412-7250 11 Bolt, 1/2" x 1"
38 412-0058 11 Hex Nut, 1/2"
39 412-0072-01 11 Flat Washer, 1/2"
40 105-7010-R 1 A-Frame, 5’ right
41 105-7010-L 1 A-Frame, 5’ left
42 412-0076 4 Flatwasher, 5/8
Options - Not Shown:
43 101-6798 1 5' Chain Guard - Front
44 101-6799 1 5' Chain Guard - Rear
5' CoMPetitorrr Main asseMBLy Parts
