Technical Data E 320 Rims – Tires
Model E 320 (210 065)
1
Rims
E 320 with AWD (210 082) 1 (light alloy rims) 7 1 /² J x 16 H 2
Wheel offset 41 mm (1.6 in)
Engine 112
All season tires:
Mode of operation 4-stroke engine, Radial-ply tires 215/55 R 16 93 H
gasoline injection Winter tires:
No. of cylinders 6 Radial-ply tires 215/55 R 16 93 H M+S
Bore 89.90 mm (3.54 in)
Stroke 84.00 mm (3.30 in)
Electrical System
Total piston displacement 3199 m³ (195.2 cu.in)
Compression ratio 10:1 Generator (alternator) 14 V/90 A
Output acc.to SAE J 1349 162 kW/5500 rpm Starter motor 12 V/1.7 kW
(217 hp/5500 rpm) Battery 12 V/100 Ah
Maximum torque acc. to SAE J 1349 315 Nm/3850 rpm Spark plugs Bosch F 8 DPER
(232 ft-lb/3850 rpm) Electrode gap 0.8 mm (0.032 in)
Maximum engine speed 6400 rpm Tightening torque 15-22 ft.lb. (20-30 Nm)
Firing order 1-4-3-6-2-5
Poly – V belts length 2390 mm
1
The quoted data apply only to the standard vehicle. See
an authorized Mercedes-Benz dealer for the corresponding
data of all special bodies and special equipment.
