142
Technical Data Rims – Tires
Model E 300 DIESEL (210 025) 1 Rims
(light alloy rims) 7 1 /² J x 16 H 2
Wheel offset 41 mm (1.6 in)
Engine 606
All season tires:
Mode of operation Diesel 4-stroke Radial-ply tires 215/55 R 16 93 H
Winter tires:
No. of cylinders 6 Radial-ply tires 215/55 R 16 93 H M+S
Bore 87.00 mm ( 3.43 in)
Stroke 84.00 mm ( 3.31 in)
Electrical System
Total piston displacement 2996 m³ (182.8 cu.in)
Compression ratio 22:1 Generator (alternator) 14 V/120 A
Output acc.to SAE J 1349 174 kW/4400 rpm Starter motor 12 V/2.2 kW
(130 hp/4400 rpm) Battery 12 V/100 Ah
Maximum torque acc. to SAE J 1349 330 Nm/2600 rpm
(243 ft-lb/2600 rpm)
Maximum engine speed 5200 rpm
Firing order 1-5-3-6-2-4
Poly – V belts length 2140 mm
1 The quoted data apply only to the standard vehicle. See
an authorized Mercedes-Benz dealer for the corresponding
data of all special bodies and special equipment.
