Macintosh System
Minimum Requirements:
• Minimum Apple G4 processor , 128MB RAM
• e-SATA :With support for Port-Multiplier function
• USB 2.0 equipped Mac: Mac O.S. 10.X or Later
Windows System
Minimum Requirements:
• Minimum Intel Pentium III CPU 500MHz, 128MB RAM
• e-SATA :With support for Port-Multiplier function
• USB 2.0 equipped PC: Windows XP, Vista, Windows 7
• USB 3.0 equipped PC: Windows XP, Vista, Windows 7
Package Contents
• RAID enclosure X 1
• External Power Adapter: AC Input 100-240V~1.6A,
DC Output 5V / 12V 2A X 1
• Power Cord X 1
• USB3.0 X 1
• e-SATA cable X 1
• Screw Driver X 1
System Requirements
RAID 1 MIRRORING MODE
RAID 1– Mirroring: Using this mode will require 2 identical HDDs;
meaning they must be the same capacity, brand and model number. Under RAID1,
it will create an extra copy (or mirror) set of data to second drive.
The backup data are more important for safe keeping and
the available data only show up in one large single drive.
This is useful when first HDD fails and it can be replaced by second set
of identical data instantly.
Same capacity / Brand HDD
3TB
RAID 0 SPANNING MODE
RAID 0 - Spanning: Two HDDs will show up as one large single drive.
Spanning is an array (not RAID) that is written sequentially across two drives.
Same capacity / Brand HDD
3TB
3TB
6TB
