KTD-S0023-A Page 21 JIDA32 Interface
KTLX800/pITX Software Guide
8.6 Digital I/O Part
This part defines the availability of digital input/output lines.
Type Port Pin Count Position
Input or Output 0 8 Bit 0 - 7
Input or Output 1 8 Bit 0 - 7
Input/Output 2 - 7 Not supported
8.7 Watchdog Part
The watchdog can be programmed with discrete timeout values on boards with CPLD implementation or in
millisecond resolution with boards using a Super-I/O. In the discrete value scenario if there is no exact
match to the timeout value the next higher one is used (Example KTLX800/pITX: programmed value = 12
seconds, activated value = 30 seconds).
Type Steps Timeout Values Result
CPLD 7
1, 5, 10, 30 seconds
1, 5, 10 minutes
RESET
NMI not supported
