Om6040 shelf - perspective view - 4, Introduction om6040 – Kontron OM6040 Compact User Manual
Page 18
ID 1027-6427, Rev. 2.0
Introduction
OM6040
Page 1 - 4
The following figure illustrates the OM6040 shelf configured with the AM4901 MCH. The chas-
sis is provided with a wall-mount panel on the left side of the chassis. The cooling fans are lo-
cated at the bottom of the chassis and the power supply at the rear. These units are not user-
serviceable.
Figure 1-1: OM6040 Shelf - Perspective View
Mounting Holes
MCH
AMC 1
SLOT
AMC 2
SLOT
AMC 3
SLOT
AMC 4
SLOT
