MSMGE104EX / Introduction
www.kontron.com 7
2 Introduction
2.1 MSMGE104EX Ordering Information
Part / Option Part Number Description
MSMGE104ex 801730 1GE-LAN with PCIe
2.2 Understanding MSMGE104EX Functionality
The MICROSPACE ® PCI/104-Express expansion card MSMGE has a PCI Express 1 GB LAN controller. The product permits
connection to the 1 GB/s Ethernet by means of the full utilization of the PCI Express bus bandwidth (2.5 GB/s).
» 1 GB LAN
» PCI Express bus
» 2x USB
» PCI104: pass-through
» The MSMGE104EX is PCI/104-Express, version 1.0, compliant.
2.3 MICROSPACE
®
Documentation
This manual is written for the original equipment manufacturer (OEM) who plans to build computer systems based on
the single board MICROSPACE-PC. It is for integrators and programmers of systems based on the MICROSPACE-
Computer family. This manual provides instructions for installing and configuring the board and describes the system
and setup requirements. This document contains information on hardware requirements, interconnections, and
details of how to program the system. Please check the Product CD for further information and manuals.
2.4 MSMGE104EX Benefits
MICROSPACE PCI/104-Express embedded computer boards comply with the PC/104 Consortium form factor 3.55 ×
3.775 inches (90.17 × 95.89 mm) and are available in "stack through" versions.
