AM4150 Introduction
ID 1051-5040, Rev. 2.0 Page 1 - 9
1.5 Technical Specification
Table 1-2: AM4150 Main Specifications
AM4150 SPECIFICATIONS
Processor
CPU The AM4150 supports the following microprocessors:
• Freescale™ QorIQ™ P5020 processor, 2.0 GHz, 800 MHz platform freq.
• Freescale™ QorIQ™ P5020 processor, 1.6 GHz, 600 MHz platform freq.
Further processor features:
• Two 64-bit execution cores
• System Memory interface with optimized support for dual-channel
DDR3 SDRAM memory at 1300 MHz with ECC for the QorIQ™ P5020
processor with 2.0 GHz CPU frequency
• System Memory interface with optimized support for dual-channel
DDR3 SDRAM memory at 1200 MHz with ECC for the QorIQ™ P5020
processor with 1.6 GHz CPU frequency
Integrated controllers Controllers integrated in the CPU and utilized by the AM4150: eSDHC, eLBC,
DUART, dTSEC, PCIe, sRIO, SPI, I²C.
Memor
y
Memory Main memory:
• Up to 8 GB, dual-channel DDR3 SDRAM memory with ECC running at
up to 1300 MHz
Cache structure:
• 64 kB L1 cache for each core
• 32 kB instruction cache
• 32 kB data cache
• 512 kB backside L2 cache for each core
• 2 MB shared L3 CoreNet platform cache (1 MB per memory channel)
Flash memory:
• Two SPI boot flashes (2 x 2 MB) for U-Boot selectable via the DIP switch
or the MMC
• One 8 MB SPI flash for operating system use
Mass storage device:
• Up to 2 GB NAND flash via an integrated/embedded NAND flash controller
• Up to 32 GB microSDHC flash via an integrated SDHC controller
• Up to 64 GB NAND flash memory (SSD) via an optional onboard SATA
Flash module
Two serial EEPROMs with 64 kbit:
• One for system data storage
• One free for user data storage
