Introduction AM4140
Page 1 - 10 ID 1046-4973, Rev. 1.0
P R E L I M I N A R Y
AMC Interconnection
Gigabit Ethernet Common Options Region ports 0-1:
• Two Gigabit Ethernet SerDes ports (port 1 switchable to front)
Fat Pipes Region ports 8-11:
• Four x1 Gigabit Ethernet SerDes ports
SRIO Fat Pipes Region ports 4-7 and 8-11:
• One 4x Serial RapidIO interface operating in host or agent configuration
PCI Express Fat Pipes Region ports 4-7 and 8-11:
• One x4 PCI Express interface operating in root complex configuration
XAUI Fat Pipes Region ports 8-11:
• One XAUI interface
Debug Interface Extended Options Region port 14:
• One debug port
Serial Interface Extended Options Region port 15:
• One serial port
Clock Clock:
• Bidirectional PCI express reference clock (FCLKA)
Connectors
Front Panel
Connectors • Two Gigabit Ethernet ports on two RJ-45 connectors, J2 and J3
• One serial port (UART1) with RS-232 signal level on RJ-45 connector, J4
Onboard Connector • Common on-chip processor (COP) debug port via 16-pin (2 x 8) pinrow
1.27 mm connector, J8
microSD card Socket • Standard microSD socket, J9, accepts microSD and microSDHC cards
AMC Card-edge
Connector • One 170-pin AMC Card-edge connector, J1
Switch
DIP Switch One DIP switch for board configuration, SW2, consisting of four switches
LEDs
Module Management
LEDs • LED1 (red): Out-of-Service LED
• LED2 (red/green/amber): Health LED
• HS LED (blue): The hot swap indicator provides basic feed-
back to the user on the hot swap state of the
module. The HS LED states are off, short
blink, long blink, and on.
User-Specific LEDs • ULED3 (red/green): AMC port 0 link status (green) + debug code
(green) + general purpose (red/green/
red+green)
• ULED2 (red/green): AMC port 1 link status (green) + debug code
(green) + general purpose (red/green/
red+green)
• ULED1 (red/green): Debug code (green) + general purpose (red/
green/red+green)
• ULED0 (red/green): Debug code (green) + general purpose (red/
green/red+green)
Integral Ethernet
LEDs • Act (green): Ethernet Link /Activity
• Speed (green/yellow/off): Ethernet Speed
Table 1-2: AM4140 Main Specifications (Continued)
AM4140 SPECIFICATIONS
