Introduction AM4140
Page 1 - 8 ID 1046-4973, Rev. 1.0
P R E L I M I N A R Y
1.4.3 Board Layouts
Figure 1-3: AM4140 Board Layout (Top View)
Figure 1-4: AM4140 Board Layout (Bottom View)
Note ...
The AM4140 is also available with retaining screws on the front panel. For further
information, please contact Kontron.
Freescale™
QorIQ™
Octal-Core P4080/
Quad-Core P4040
J1
1
85
J3
GbE A
J2
GbE B
Heat Sink
DDR3 Memory
J4
AMC
GbE
PHY
Front
GbE
PHY
Standard SPI Boot Flash
NAND
Flash FPGA
MMC
SPI Flash
for OS
Board Temp. Sensor
Air Temp.
Sensor
J1
170
ON
SW2
DDR3 Memory
MicroSD
Card
Socket
NAND
Flash
Board Temp. Sensor
J8
1
2
15
16
86
J9
Recovery SPI Boot Flash
