Functional Description AM4120 IPMI Firmware
Page 22 ID 1045-9586, Rev. 1.0
4.2 Sensor Thresholds
The AM4120 CPU module is available for two different operating temperature ranges. For each
operating temperature range, a set of temperature thresholds for the sensors is defined. The
standard temperature range uses thresholds defined by Table 11, and the extended tempera-
ture range uses thresholds defined by Table 12. Table 13 provides voltage sensor thresholds.
Table 11: Thresholds - Standard Temperature Range
Sensor Number /
ID String
0Eh /
A1:Temp
Board
0Fh /
A1:Temp
AMC In
Upper non-recoverable 75 °C 75 °C
Upper critical 70 °C 70 °C
Upper non-critical 65 °C 65 °C
Normal max. 60 °C 60 °C
Nominal 55 °C 55 °C
Normal min. 0 °C 0 °C
Lower non-critical -5 °C -5 °C
Lower critical -7 °C -7 °C
Lower non-recoverable -10 °C -10 °C
Table 12: Thresholds - Extended Temperature Range
Sensor Number /
ID String
0Eh /
A1:Temp
Board
0Fh /
A1:Temp
AMC In
Upper non-recoverable 90 °C 90 °C
Upper critical 85 °C 85 °C
Upper non-critical 80 °C 80 °C
Normal max. 75 °C 75 °C
Nominal 70 °C 70 °C
Normal min. 0 °C 0 °C
Lower non-critical -40 °C -40 °C
Lower critical -42 °C -42 °C
Lower non-recoverable -45 °C -45 °C
