A.2 SFP+ Connectors
B37 GND B79 GND B122 GND B165 TCLK
B38 RxD3+ (N.C.) B80 REFCLK+ B123 RxD14- (N.C.) B166 TMS
B39 RxD3- (N.C.) B81 REFCLK- B124 RxD14+ (N.C.) B167 TRST#
B40 GND B82 GND B125 GND B168 TDO
B41 ENABLE# B83 PS0# B126 TxD14- (N.C.) B169 TDI
B42 12V B84 12V B127 TxD14+ (N.C.) B170 GND
B85 GND B128 GND
Pin Number Signal Pin Number Signal
1 VeeT 11 VeeR
2 Tx Fault 12 RD-
3 Tx Disable 13 RD+
4 SDA 14 VeeR
5 SCL 15 VccR
6 MODABS 16 VccT
7 Rate Select 0 17 VeeT
8 LOS 18 TD+
9 Rate Select 1 19 TD-
10 VeeR 20 VeeT
Pin Signal Pin Signal Pin Signal Pin Signal
