2.4.7
Hot-Swap Process
The AM4320 AMC has the ability to be hot-swapped in and out of an AMC Carrier/Chassis. The onboard MMC
manages the AMC's power-up and power-down transitions. The list below illustrates this process for a power-
down request.
1 Ejector latch is opened. HOT_SWAP_PB# assertion. MMC firmware detects the assertion of this signal.
2 MMC sends "Module Handle Open" event message to AMC Carrier. The corresponding M state of AMC
moves from M4-> M5.
3 AMC moves from M5 -> M6 if the ShMC grants the request and then sends the FRU Control requesting
quiesced state to the AMC.
4 The firmware deasserts payload power and sends "Module Quiesced" event message to the AMC where it
transitions from M6 to M1 state.
2.5
LEDs Signification
2.5.1
Hot Swap (Blue)
Solid On (100 % on):
FRU Inactive
Long Blink ( 90 % on):
FRU Activation Request / FRU Activation In Progress
Solid Off ( 0 % on):
FRU Active
Short Blink ( 10 % on):
FRU Deactivation Request / FRU Deactivation In Progress
2.5.2
Out of service (Red/Amber)[default : red]
Solid On:
IPMC in reset
Fast Blink (~50 % on):
IPMC upgrade/rollback in progress
Short Blink (10 % on):
FRU Power Denied
Application Defined:
May be controlled by application using PICMG API
2.5.3
Health Led(Amber/Green)[default : green]
Green: Health
Ok
Amber: Health
Error
(Critical)
Application Defined:
May be controlled by application using PICMG API
