12 AM4301
www.kontron.com
3. Installing the Board
3.1 Onboard Interconnectivity
3.1.1 Onboard Connectors and Headers
Table 3-1: Onboard Connectors and Headers
3.2 Board Hot Swap and Installation
Some precautions must be taken when connecting or disconnecting a board to:
1 Rail guides must be installed on the enclosure to slide the board to the backplane.
2 Do not force the board if there is mechanical resistance while inserting the board.
3 Use extractors handle to disconnect and extract the board from its enclosure.
3.2.1 Installing an AMC
To install an AMC:
1 Remove the AMC filler panel.
2 Carefully engage the AMC into the card guide. Push the AMC until it fully mate with it's connector. Secure
the AMC handle to the locking position.
3 In normal condition, the blue LED shall turn ON as soon as the AMC is fully inserted. It will turn OFF at the
end of the hot swap sequence.
Description Connector Comments
AMC Connector J1 AMC Connector
Manufacturing Connector J3 Reserved
Ethernet Connectors J4 4 Ethernets connectors populated
WARNING
Always use a grounding wrist wrap before installing or removing the board from a
chassis.
