2.4.2
Hardware Sensors
Table 2-2: Hardware Sensors
Sensor Name
Voltage/Signals Monitored
Scanning Enabled
under Power
State
Health LED
(Green to Red)
IPMI Info-1
Internal IPMC firmware diagnostic
*
N
IPMI Info-2
Internal IPMC firmware diagnostic
*
N
FRU Agent
Board FRU Data agent that verify FRU Data validity
*
N
ModuleHotSwap
AMC HS State
*
N
IPMBL State
Operational state of IPMB-L
*
N
Storage Err
Management sub-system health: non volatile memory
error.
*
N
Board 3.3V
3.3 V
-
X
Board 3.3VSUS
3.3 V Suspend
*
X
Board 12.0v
12.0 V
-
X
Board BlueLed
5.0 V
*
X
Board 1.8V
1.8 V
-
X
Board Vtt1.5V
1.5 V Vtt
-
X
Board 1.1V
1.1 V
-
X
Board 1.0V
1.0 V
-
X
Temp AirInlet
Board Inlet Temperature
-
X**
Temp LAN A
Temperature LAN A 82571EB chip
*
X**
Temp LAN B
Temperature LAN B 82571EB chip
*
X**
Temp Switch
Temperature PCIE switch PEX8517
*
X**
Temp Exhaust1
Board Outlet 1 Temperature
*
X**
Temp Exhaust2
Board Outlet 2 Temperature
*
X**
Lan1 10M Lnk
LAN-1 link detection at 10 Mbit
-
N
Lan1 100M Lnk
LAN-1 link detection at 100 Mbit
-
N
Lan1 1G Lnk
LAN-1 link detection at 1 Gbit
-
N
Lan2 10M Lnk
LAN-2 link detection at 10 Mbit
-
N
Lan2 100M Lnk
LAN-2 link detection at 100 Mbit
-
N
Lan2 1G Lnk
LAN-2 link detection at 1 Gbit
-
N
Lan3 10M Lnk
LAN-3 link detection at 10 Mbit
-
N
Lan3 100M Lnk
LAN-3 link detection at 100 Mbit
-
N
Lan3 1G Lnk
LAN-3 link detection at 1 Gbit
-
N
Lan4 10M Lnk
LAN-4 link detection at 10 Mbit
-
N
Lan4 100M Lnk
LAN-4 link detection at 100 Mbit
-
N
Lan4 1G Lnk
LAN-4 link detection at 1 Gbit
-
N
PexLaneGood 0
PCIE lane 0 detection
-
N
PexLaneGood 1
PCIE lane 1 detection
-
N
PexLaneGood 2
PCIE lane 2 detection
-
N
PexLaneGood 3
PCIE lane 3 detection
-
N
PexLaneGood 4
PCIE lane 4 detection
-
N
