7 AM4510
www.kontron.com
2.4.2.2 Module Hot Swap
The hot-swap event message conveys the current state of the module, the previous state, and a cause of the
state change as determined by the MMC. Refer to AMC.0 R2.0 Specifications for further details on the module
hot-swap state.
2.4.2.3 Temperature Sensors Location
Figure 2-2:Temperature Sensors Location
2.4.3 Field Replaceable Unit (FRU) Information
The FRU Information provides inventory data about the board where the FRU Information Device is located.
The part number or version number can be read through software.
FRU information in the AM451x includes data describing the AM451x board as per AMC.0 R2.0 specification
requirements. This information is retrieved by the Carrier AMC, enabling reporting of board-specific
information through a standardized mechanism.
Following are the definitions for the multirecord implemented by the firmware as part of Module data.
Note:
Component Side 2 is on the Hard disk side
Note:
Temperature values are provided for reference only; they should not be used for system calibration.
