7 AM4521
www.kontron.com
2.5.1 AMC Port Assignments
The AM4521 connects up to two ports on the AMC connector. These are defined by the AMC.3 specification for
serial storage. The link type and link type extension are defined in the table below.
Table 2-4:AM4521 E-Key Port Assignments
2.6 Supported IPMI Commands
The MMC communicates with the carrier controller through the local IPMB-L bus of the carrier and responds
to all mandatory commands for AMC Module Management Controllers (as defined in the AMC Specification),
as well as some optional ones.
Table 2-5:Supported IPMI Commands
Port # Port Name Link type AMC port map region
0 unused
1 unused
2 Channel 0
Link type 7 = AMC.3 Storage,
Link type extension = 2 (SAS/SATA)
AMC Asymmetric Match = 00b (SAS)
Common Options
3 Channel 1
Link type 7 = AMC.3 Storage,
Link type extension = 2 (SAS/SATA)
AMC Asymmetric Match = 00b (SAS)
Common Options
4-20 unused
Command IPMI/PICMG/AMC Spec NetFn CMD MMC Req
IPM Device "Global" Commands
Get Device ID
17.1 App 01h Mandatory
Broadcast "Get Device ID 17.9 App 01h Mandatory
Messaging Commands
Send Message
18.7 App 34h Optional
Event Commands
Platform Event
23.3 S/E 02h Mandatory
Sensor Device Commands
Get Device SDR Info
29.2 S/E 20h Mandatory
Get Device SDR 29.3 S/E 21h Mandatory
Reserve Device SDR Repository 29.4 S/E 22h Mandatory
Get Sensor Reading Factors 29.5 S/E 23h Optional
Set Sensor Hysteresis 29.6 S/E 24h Optional
Get Sensor Hysteresis 29.7 S/E 25h Optional
Set Sensor Threshold 29.8 S/E 26h Optional
Get Sensor Threshold 29.9 S/E 27h Optional
Set Sensor Event Enable 29.10 S/E 28h Optional
