2.5 Sensor Data Records
The MMC monitors the status of the module and provides this data so the shelf manager can read it. Below are
the SDRs that the AM4521 module creates.
Table 2-2:Sensor Data Records
The AM4521 includes the standard FRU data records per the IPMI Platform Management FRU Information
Storage Definition, Board Info Area. The AM4521 includes additional FRU records as defined in the PICMG 2.9
specification.
Table 2-3:Standard FRU Data Records
Sensor UNR UC UNC LNC LC LNR ID String
1.8V 1.98 1.93 1.90 1.70 1.67 1.62 +1.8V
5.0V 5.50 5.35 5.25 4.75 4.65 4.5 +5V
12V 13.60 13.40 13.00 11.00 10.60 10.400 +12V
Board Temp (LM60) 80 70 60 N/A N/A N/A Board Temp
Inlet Temp (LM75) 70 60 50 N/A N/A N/A Inlet Temp
Board Information AM4521
Version 1
Language Code 25 (EN-English)
MFG date.time
Manufacturer Name
Kontron
Product Name AM4521
Product Serial Number 068LYMMSSSS
Product Part / Model# AM4521
Product Version A
