Hot Swap and Installation

15

RTM8050

www.kontron.com

3.2

RTMHDD Hot Swap and Installation

3.2.1

Installing the Hot Swap RTMHDD

To install the RTMHDD:

1 Carefully engage the RTMHDD into the guide. Push it until it fully mate with its connector. Secure

the hard disk handle to the locking position.

2 The blue LED shall turn ON as soon as the RTMHDD is fully inserted. It will turn OFF at the end of the

hot swap sequence.

3.2.2

Removing the Hot Swap RTMHDD

To remove the RTMHDD:

1 Pull out the handle to unlock the RTMHDD.

2 Wait for the blue LED to turn solid on (100% on).

3 Pull out the RTMHDD using the handle.
