Board Features
9 RTM8050
www.kontron.com
2.8.2 Hardware Sensors
Table 2-3:IPMI Hardware Sensors
X Exceed critical threshold / Error Assertion
* Power On/Off
- Power On
N No change
IPMI
sensor
ID Sensor Name Description (Sensor Type, Event trigger) Scanning En-
abled under
Power State Health LED
(Green to Am-
ber)
0 Module HS Hot Swap state * N
1 Temp Air In Ait Inlet Temperature (Degrees) * X
2 Temp Air Out Ait Outlet Temperature (Degrees) * X
3 Temp SASCtrl LSI SAS Controller Temperature (Degrees) * X
4 Temp MMC Module Management Controller Temperature (Degrees) * X
5 Vcc +3.3VSUS Voltage on board 3.3V suspend (management) power supply * X
6 Vcc +3.3V Voltage on board 3.3V backend power supply - X
7 Vcc +5V Voltage on board 5V backend power supply - X
8 Vcc +1.2V Voltage on board 1.2V backend power supply - X
9 Vcc BlueLED Voltage on board blue LED VPUMP suspend power supply * X
10 Vcc +12V Voltage on board 12V payload power supply - X
11 Vcc +12VDisk Voltage on board 12V payload disk power supply - X
12 SFP-A Pres SFP-A Slot/Connector Status -
13 SFP-A OC SFP-A Over Current Status - X
14 SFP-B Pres SFP-B Slot/Connector Status -
15 SFP-B OC SFP-B Over Current Status - X
16 USB0 OC USB Over Current Status - X
17 USB1 OC USB Over Current Status -
18 Disk Bay Removable Disk Bay Slot/Connector Status * X
19 Power State Board Power State * X
20 Power Good Actual power good status * X
21 Pwr Good Ev Power good status event that occur since the last power on or reset - X
22 Health Error General health status *
23 Ver change Firmware Change Detection *
24 IPMBL State IPMB-L branch from FRU0 fault detection sensor *
25 FRU Agent FRU Information Agent - FRU0 Data Error Detection *
26 MMC Reboot IPMC reboot detection *
27 MMC FwUp Kontron OEM IPMC firmware upgrade Status *
28 MMC Stor Err Management sub-system health: non volatile memory error *
29 IPMI Info-1 Internal Management Controller firmware diagnostic *
30 IPMI Info-2 Internal Management Controller firmware diagnostic *
