Table 3-11: AMC B2 Channel Assignment

Channel

Region

Connection

0

GbE

Local Base Switch 0/23

1

GbE

-

2

SATA/FC

AMC B1, channel 2

3

SATA/FC

RTM, STOR1

4

Fabric

-

5

Fabric

-

6

Fabric

-

7

Fabric

-

8

Fabric

-

9

Fabric

-

10

Fabric

-

11

Fabric

-

12

-

-

13

Extended

-

14

Extended

-

15

Extended

-

16

Extended

-

17

Extended

RTM, AMC_B2_P17

18

Extended

RTM, AMC_B2_P18

19

Extended

RTM, AMC_B2_P19

20

Extended

RTM, AMC_B2_P20
