User Guide
CPS3101
1.4 Standards
This product complies with the requirements of the following standards.
In addition, boards ordered with the ruggedized service comply with the following standards as well.
Note: Customers desiring to perform further environmental testing of the CPS3101 must contact
Kontron for assistance prior to performing any such testing.
Boards
without conformal coating must not be exposed to a change of temperature which
can lead to condensation, as it may cause irreversible damage especially when the board
is powered up again.
Kontron does not accept any responsibility for damage to products resulting from destruc-
tive environmental testing.
1.5 Related Publications
The following publications contain information relating to this product.
Table 2: Standards
TYPE ASPECT STANDARD
CE Emission EN55022, EN50121-3-2, EN61000-6-3
Immission EN55024, EN50121-3-2, EN61000-6-2
Electrical Safety EN60950-1
Mechanical Mechanical Dimensions IEEE 1101.10
Environmental Climatic Humidity IEC60068-2-78
WEEE Directive 2002/96/EC
Waste electrical and electronic equipment
RoHS 2 Directive 2011/65/EU
Restriction of the use of certain hazardous sub-
stances in electrical and electronic equipment
Table 3: Additional Standards for Boards Ordered with Ruggedized Service
TYPE ASPECT STANDARD REMARKS
Environmental Vibration
(Sinusoidal) IEC60068-2-6
IEC61131-2 Ruggedized version test parameters:
9-150 (Hz) frequency range
1 (g) acceleration
1 (oct/min) sweep rate
10 cycles/axis
3 axis
Single Shock IEC60068-2-27
IEC61131-2 Ruggedized version test parameters:
15 (g) acceleration
11 (ms) shock duration half sine
3 number of shocks per direction (total: 18)
6 directions
5 (s) recovery time
Table 4: Related Publications
PRODUCT PUBLICATION
CompactPCI Serial Systems PICMG® CPCI-S.0 R 1.0 CompactPCI® Serial Specification
All Kontron products Product Safety and Implementation Guide, ID 1021-9142
