8-11
Cisco Unified IP Phone 7961G/7961G-GE and 7941G/7941G-GE Administration Guide for Cisco Unified CallManager
OL-11528-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Statistics
Table 8-3
Ethernet Information Items
Item
Description
Tx Frames
Total number of packets transmitted by the phone
Tx broadcast
Total number of broadcast packets transmitted by the phone
Tx multicast
Total number of multicast packets transmitted by the phone
Tx unicast
Total number of unicast packets transmitted by the phone
Rx Frames
Total number of packets received by the phone
Rx broadcast
Total number of broadcast packets received by the phone
Rx multicast
Total number of multicast packets received by the phone
Rx unicast
Total number of unicast packets received by the phone
RxPacketNoDes
Total number of shed packets caused by no DMA descriptor
Table 8-4
Access Area and Network Items
Item
Description
Rx totalPkt
Total number of packets received by the phone
Rx crcErr
Total number of packets received with CRC failed
Rx alignErr
Total number of packets received between 64 and 1522 bytes in length that
have a bad FCS
Rx multicast
Total number of multicast packets received by the phone
Rx broadcast
Total number of broadcast packets received by the phone
Rx unicast
Total number of unicast packets received by the phone
Rx shortErr
Total number of FCS error packets or Align error packets received that are
less than 64 bytes in size
Rx shortGood
Total number of good packets received that are less than 64 bytes size
Rx longGood
Total number of good packets received that are greater than 1522 bytes in size
Rx longErr
Total number of FCS error packets or Align error packets received that are
greater than 1522 bytes in size
Rx size64
Total number of packets received, including bad packets, that are between 0
and 64 bytes in size
