7 Hinge side mounting
Screws provided are for mounting
directly into wood. If mounting into
brick, drywall or other surfaces, use
appropriate hardware. If installing into
hardwood (i.e. oak), drilling a pilot
hole may be necessary. Cut out
templates along all dotted lines, separating
template (a) from (b). Hold template (a)
vertically and completely outstretched
against mounting surface with the end
marked ” ” even with the floor. Mark screw
hole positions. Remove the template
8
Use longer screws for mounting
into studs behind drywall. Using 2 wood
screws (K) mount upper hinge bracket (L)
with the hole and the post pointing up, in
top 2 screw hole positions. Using 2 wood
screws (K) mount lower hinge bracket (M)
with angled side facing down, in bottom 2
screw hole positions.
9 Locking Side Mounting
Screws provided are for mounting
directly into wood. If mounting into
brick, drywall or other surfaces, use
appropriate hardware. If installing into
hardwood (i.e. oak), drilling a pilot
hole may be necessary. Hold template
(B) vertically and completely outstretched
against mounting surface with the end
marked ” ” even with the floor. Mark screw
hole positions. Remove the template.
8
9
L
K
M
K
7
G2200/G2201
Angle Mount Safeway Select
® G2200/G2201
Angle Mount Safeway Select
®
G2200/G2201 Angle Mount Safeway Select
®
27
