Power Distribution Center (Diesel Engines)
Cavity Fuse Description
F1 40 Amp
Green Blower Motor
F2 40 Amp
Green Radiator Fan
F3 50 Amp Red JB Power
F4 40 Amp
Green ABS Pump
F5 Open
F6 30 Amp Pink ASD
F7 50 Amp Red JB Power
F8 40 Amp
Green Ign/Start
F9 50 Amp Red JB Power
F10 30 Amp Pink Trailer Tow
F11 20 Amp Yel-
low Fuel Heater
Cavity Fuse Description
F12 30 Amp Pink Light Bar
F13 40 Amp
Green Windows
F14 40 Amp
Green Ignition Switch
F15 50 Amp Red JB Power
F16 15 Amp Blue ASD Feed
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger (HBL)
F20 Open
F21 20 Amp Yel-
low A/C Clutch
F22 Open
F23 Open
F24 Open
MAINTAINING YOUR VEHICLE 359
7
