Cavity Fuse Description
F16 Open
F17 Open
F18 Open
F19 30 Amp Pink Rear Window Defogger
(HBL)
F20 Open
F21 20 Amp Yellow A/C Clutch
F22 Open
F23 Open
F24 20 Amp Yellow Fuel Pump
F25 20 Amp Yellow ABS Valves
F26 25 Amp Natural Injectors
F27 Open
F28 15 Amp Blue Starter
R29 Half ISO Relay Fuel Pump
R30 Half ISO Relay Starter
Cavity Fuse Description
R31 Half ISO Relay Wiper On/Off
R32 Half ISO Relay Wiper Hi/Lo
R33 Full ISO Relay H. Blower
R34 Full ISO Relay Rad. Fan Hi
R35 Half ISO Relay A/C Clutch
R36 Open
R37 Half ISO Relay NGC Trans
R38 Open
R39 Full ISO Relay ASD
R40 Full ISO Relay Rad. Fan Lo
