Cavity Fuse/Color Description
1 40 Amp Green HVAC Blower
2 30 Amp Pink Power Outlets
3 30 Amp Pink Rr Wiper/Ign R/O
4 30 Amp Pink ABS Pump
5 Spare
6 50 Amp Red ASD
7 Spare
8 40 Amp Green Acc Delay/Seats
9 Spare
10 40 Amp Green Starter/JB Power
11 30 Amp Pink Cig Ltr/T-Tow
12 40 Amp Green EBL/Htd Mirror
13 40 Amp Green JB Power
14 Spare
15 Spare
Cavity Fuse/Color Description
16 25 Amp Natu-
ral IPM/Coils
17 Spare
18 20 Amp Yellow TCM/AC Clutch
19 20 Amp Yellow Ign Sw
20 20 Amp Yellow PCM Batt (Gasoline Only)
21 30 Amp Pink ABS Valves
22 Spare
23 20 Amp Yellow FDCM
24 20 Amp Yellow Fuel Pump
25 20 Amp Yellow FDCM/E-Diff.
26 Spare
27 15 Amp Blue Brake/Stop Lamps
28 25 Amp Natu-
ral NGC/Injectors
29 Spare
